Dare Super Constellation

Dare Super Constellation by Brodak
Item#

Quick Overview

DA-560
Availability: In stock
$362.50
Qty:

Quick Overview

The Super Constellation was designed as an electric R/C powered 1:25-scale model of one of the most elegant airliners of all time. The "Connie" is built primarily of balsa and ply with plastic detail parts in key areas to simplify construction. Designed for clean, quiet electric power and 4-channel RC. Due to the complexity and added weight, no provisions were made for retracts. It was designed in the old-school style "stick and tissue" construction to build a light, economical model with simple 4-channel R/C and electric power that can be easily flown in smaller venues, but is large enough to be flown on conventional R/C flying fields.

The "Connie" served only 2 years as an airliner from 1954 - 1956, but also served the roll of a military transport as well as "Columbine III", President Eisenhower's personal airplane.

Specifications

Wing Span: 60" Plane Length: 55.6" Wing Area: 390 sq. in.

Details

Wingspan: 60”,   Length: 55.6”   Flying Wt: 47.6 oz.  Wing area: 390 sq. in.  W/loading: 12-oz/sq. ft.

Scale: 1:25.0    Power: (4) Suppo 2212/13T, 1000KV Outrunner motors w/four 12-Amp ESC, four 9-6E props, one 2200 mah 3S (30C Min) Li-Poly battery.  Guidance: 4-ch R/C using 4-Suppo SP-9 servos (or equivalent)

W/loading 12 oz/sq. ft.

This Kit Requires the Following

(4) BH-2066 RimFire 400 Outrunner Brushless Motor (KV950)

(4) BH-1862 12 AMP ESC

(1) BH-1904  2200 3S Lipo Battery

(4) LP-09060E Props









Additional Information

SKUDA-560

Kit Features

Laser cut parts, pre bent landing gear, the best balsa you'll ever find in a kit, vacuum formed parts, full size plans, instructions, brass tubing, hardware and decals
